320W N-Type Solar Panel Bundle- Renogy
$599.99
Description
Key Features
- Up to 25% cell efficiency with N-TYPE tech and 18 busbars
- Space-saving design — 13.5% smaller, 17.2% lighter
- Superior power output in high-temperature conditions
- IP68 rated — built to withstand snow, rain, and heat
- 10-year product & 25-year power output warranty
- Dimensions: 64.6*34.7*1.4 inch
Reliable
- Better Performance from advanced N-Type cells. These N- Type cells help the compact panel generate more usable energy throughout the day while maintaining stronger long-term performance in outdoor conditions.
- 10 year warranty
Durable
- Guaranteed positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa).
- Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades.
- IP65 rated junction box provides complete protection against environmental particles and low pressure water jets.
Versatile
- Can be used for many different applications.
- Ground mount compatible.
- Compatible with on-grid and off-grid inverters.
Installation Ready
- Pre-drilled holes on the back of the panel allow for fast mounting and securing.
- Pre-drilled holes included for grounding.
| Specifications | |
|---|---|
|
Maximum Series Fuse Rating: 20A |
Connectors: MC4 |
| Maximum Power: 320W | Maximum System Voltage: 1000V DC (UL) |
| Optimum Operating Voltage (Vmp): 37.85V | Open-Circuit Voltage (Voc): 43.82V |
| Optimum Operating Current (Imp): 8.46A | Short-Circuit Current (Isc): 8.92A |
| Weight: 32.9 lbs / 14.9kg | Dimensions: 64.6x34.7x1.4in |
| Operating Temperature: -40°F to 185°F(-40°C to +85°C) | Panel Leads (Pair): 14AWG (4 m / 1.3 ft long) |
|
|
Power Output Warranty: 10-Year |
